Bridge Connection Unit (AX-AI)

Smart transfer system allows for a compact footprint – AUTION EYE connects with the AUTION MAX AX-4060, and results in a very small footprint (41.9” x 25.6” x 23.6”).
Save time with automation – Particles are classified automatically based on a unique algorithm.

Enables intuitive operations – provides an easy-to-see configuration on screen

Sample type	Urine
Measurement items	12 automated classification items: Red blood cells (RBC), White blood cells (WBC), White blood cell clumps (WBCC), Squamous epithelial cells (SQEC), Non-squamous epithelial cells (NSE), Hyaline casts (HYAL), Non-hyaline casts (NHC), Bacteria (BACT), Crystals (CRYS), Yeast (YST), Mucous (MUCS) and Sperm (SPRM)
Measurement principle	Flow cell digital imaging
Required sample volume	2mL
Measurement time	45 seconds/test (Excluding cases in which large numbers of formed elements are present or in the case of control measurement)
Sample loading capacity	One-way transportation (default): Maximum 50 samples Loop transportation: Maximum 100 samples
Display value	[/uL], [/HPF], [/LPF], [/WF] Values can be converted to number of elements per field Rank expression is possible
Memory capacity	Measurement results (Normal): 10,000 tests* Measurement results (QC): 1,000 tests *There is a limit to the number of saved images.
Communication	Ethernet, RS-232C
Reagents	Sheath solution, washing solution (for maintenance), control and calibrator
Dimensions	530(W) x 600(D) x 650(H) mm (20.9(W) x 23.6(D) x 25.6(H) inches) (including the sampler)
Weight	Approximately 125 lbs (57 kg)
